Sferik rolikli podşipnikler iki tarapa agyr ýükleri ýerleşdirip biler.Öz-özüňi düzýärler we sürtülme ýa-da temperatura ýokarlanman diýen ýaly gabat gelmezlik we mil defektlerini ýerleşdirýärler.Dizaýn, ýaglamagy aňsatlaşdyrýan aýratynlyklary öz içine alýar.Rulmanlar, jaýlary, ýeňleri we hozlary goşmak bilen modully ulgamda ulanylyp bilner.
Nädogry ýerleşdiriň
Loadük göterijilik ukyby
Ricaglaýyş aýratynlyklary
Pes sürtülme we uzak hyzmat ömri
Köýnege garşylygy ýokarlandyrmak
Simmetrik rulolar we ýüzýän merkezi gollanma halkasy bolan C-sferik rolik;
C dizaýnynyň CA-sferik rolikli, ýöne iki sany integralin halka flanesleri we işlenip taýýarlanan kapasasy bilen;
C dizaýnynyň CC-sferik rolikli rulmanlary, ýöne rolikleriň gowulaşmagy we sürtülmäniň peselmegi bilen;
CA dizaýnynyň CAC-sferik rolikli rulmanlary, ýöne rolikleriň gowulaşmagy we sürtülmäniň peselmegi bilen;
Üýtgedilen içerki dizaýn, göterijilik ukyby we W33 aýratynlyklary bilen “E-Standard” sferik rolikli;
J-basylan polat kafes;
K-şekilli buraw, diametri 1:12;
K30- Tapylan buraw, diametri 1:30;
M-öndürilen bürünç kafesi;
Täze element | Köne element | Gurluşy | Aýratynlyklary | Agramy / kg |
(dxDxT) mm | ||||
22205 | 3505 | MB / CA / CC / EK / CK / CMW33 | 25X52X18 | 0.18 |
22206 | 3506 | MB / CA / CC / EK / CK / CMW33 | 30X62X20 | 0.3 |
22207 | 3507 | MB / CA / CC / EK / CK / CMW33 | 35x72x23 | 0.43 |
22208 | 3508 | MB / CA / CC / E / K / CK / CMW33 | 40X80X23 | 0.55 |
22209 | 3509 | MB / CA / CC / E / K / CK / CMW33 | 45X85X23 | 0.59 |
22210 | 3510 | MB / CA / CC / E / K / CK / CMW33 | 50X90X23 | 0.64 |
22211 | 3511 | MB / CA / CC / E / K / CK / CMW33 | 55X100X25 | 0.88 |
22212 | 3512 | MB / CA / CC / E / K / CK / CMW33 | 60X110X28 | 1.19 |
22213 | 3513 | MB / CA / CC / E / K / CK / CMW33 | 65X120X31 | 1.6 |
22214 | 3514 | MB / CA / CC / E / K / CK / CMW33 | 70X125X31 | 1.68 |
22215 | 3515 | MB / CA / CC / E / K / CK / CMW33 | 75X130X31 | 1.75 |
22216 | 3516 | MB / CA / CC / E / K / CK / CMW33 | 80X140X33 | 2.12 |
22217 | 3517 | MB / CA / CC / E / K / CK / CMW33 | 85X150X36 | 2.79 |
22218 | 3518 | MB / CA / CC / E / K / CK / CMW33 | 90X160X40 | 3.78 |
22219 | 3519 | MB / CA / CC / E / K / CK / CMW33 | 95X170X43 | 4.31 |
22220 | 3520 | MB / CA / CC / E / K / CK / CMW33 | 100X180X46 | 5.06 |
22222 | 3522 | MB / CA / CC / E / K / CK / CMW33 | 110X200X53 | 7.4 |
22224 | 3524 | MB / CA / CC / E / K / CK / CMW33 | 120X215X58 | 9.267 |
22226 | 3526 | MB / CA / CC / E / K / CK / CMW33 | 130X230X64 | 11.5 |
22228 | 3528 | MB / CA / CC / E / K / CK / CMW33 | 140X250X68 | 14.5 |
22230 | 3530 | MB / CA / CC / E / K / CK / CMW33 | 150X270X73 | 18.4 |
22232 | 3532 | MB / CA / CC / E / K / CK / CMW33 | 160X260X80 | 22.3 |
22234 | 3534 | MB / CA / CC / E / K / CK / CMW33 | 170X310X86 | 28.7 |
22236 | 3536 | MB / CA / CC / E / K / CK / CMW33 | 180X320X86 | 30.5 |
22238 | 3538 | MB / CA / CC / E / K / CK / CMW33 | 190X320X92 | 35.55 |
22240 | 3540 | MB / CA / CC / E / K / CK / CMW33 | 200X360X98 | 44.7 |
22244 | 3544 | MB / CA / CC / E / K / CK / CMW33 | 220X400X108 | 63 |
22248 | 3548 | MB / CA / CC / E / K / CK / CMW33 | 240X440X120 | 83.2 |
22252 | 3552 | MB / CA / CC / E / K / CK / CMW33 | 260X480X130 | 105 |
22256 | 3556 | MB / CA / CC / E / K / CK / CMW33 | 280X500X130 | 126 |
22260 | 3560 | MB / CA / CC / E / K / CK / CMW33 | 300X540X140 | 143 |
22306 | 3606 | MB / CA / CC / E / K / CK / CMW33 | 30x70x22 | 0.37 |
22307 | 3607 | MB / CA / CC / E / K / CK / CMW33 | 35x80x31 | 0.75 |
22308 | 3608 | MB / CA / CC / E / K / CK / CMW33 | 40x90x33 | 1.07 |
22309 | 3609 | MB / CA / CC / E / K / CK / CMW33 | 45x90x33 | 1.4 |
22310 | 3610 | MB / CA / CC / E / K / CK / CMW33 | 50x110x40 | 1.83 |
22311 | 3611 | MB / CA / CC / E / K / CK / CMW33 | 55x120x43 | 2.4 |
22312 | 3612 | MB / CA / CC / E / K / CK / CMW33 | 60x130x46 | 2.88 |
22313 | 3613 | MB / CA / CC / E / K / CK / CMW33 | 65x140x48 | 3.52 |
22314 | 3614 | MB / CA / CC / E / K / CK / CMW33 | 70x150x51 | 4.21 |
22315 | 3615 | MB / CA / CC / E / K / CK / CMW33 | 75x160x55 | 5.47 |
22316 | 3616 | MB / CA / CC / E / K / CK / CMW33 | 80x170x58 | 6.19 |
22317 | 3617 | MB / CA / CC / E / K / CK / CMW33 | 85x180x60 | 7.5 |
22318 | 3618 | MB / CA / CC / E / K / CK / CMW33 | 90x190x64 | 8.96 |
22319 | 3619 | MB / CA / CC / E / K / CK / CMW33 | 95x200x67 | 9.93 |
22320 | 3620 | MB / CA / CC / E / K / CK / CMW33 | 100x215x73 | 13 |
22322 | 3622 | MB / CA / CC / E / K / CK / CMW33 | 110x240x80 | 17.95 |
22324 | 3624 | MB / CA / CC / E / K / CK / CMW33 | 120x246x80 | 22.4 |
22326 | 3626 | MB / CA / CC / E / K / CK / CMW33 | 130x280x93 | 28.2 |
22328 | 3628 | MB / CA / CC / E / K / CK / CMW33 | 140x300x102 | 35.12 |
22330 | 3630 | MB / CA / CC / E / K / CK / CMW33 | 150x320x108 | 43.7 |
22332 | 3632 | MB / CA / CC / E / K / CK / CMW33 | 160x340x114 | 52.2 |
22334 | 3634 | MB / CA / CC / E / K / CK / CMW33 | 170x360x120 | 60.7 |
22336 | 3636 | MB / CA / CC / E / K / CK / CMW33 | 180x380x126 | 70 |
22338 | 3638 | MB / CA / CC / E / K / CK / CMW33 | 190x400x132 | 81 |
22340 | 3640 | MB / CA / CC / E / K / CK / CMW33 | 200x420x138 | 94 |
